lumis.content.workflow
Class WorkflowStateConfig

java.lang.Object
  lumis.content.workflow.WorkflowStateConfig

@StableMinor(version="6.1",
             sinceVersion="4.0")
public class WorkflowStateConfig
extends java.lang.Object

Value class for content's workflow state information.

Since:

4.0.0

Field Summary

protected java.util.Map<java.lang.String,java.util.Collection<java.lang.String>>

permissionsScope

Constructor Summary

WorkflowStateConfig(org.w3c.dom.Node stateElement)
Constructs a WorkflowStateConfig, parsing its data from a state XML Element.

Method Summary

java.lang.String	getColorLight() Returns the light color for displaying this state.
java.lang.String	getColorStrong() Returns the strong color for displaying this state.
java.lang.String	getDescription() Returns the description for this state.
java.lang.String	getId() Returns the identifier for this state.
java.lang.String	getImageLarge() Returns the href for the large image icon to be used for this state.
java.lang.String	getImageSmall() Returns the href for the small image icon to be used for this state.
java.lang.String	getName() Returns the name for this state.
protected java.util.Collection<java.lang.String>	getPermissions(java.lang.Enum<?> scope) Returns all permissions available for a given scope.
java.util.Collection<java.lang.String>	getPermissions(StateScope stateScope) Returns all permissions available for a given scope.
java.util.Collection<java.lang.String>	getPermissionsScopeAll() Deprecated. Since 6.0.2, replaced bygetPermissions(Enum)
java.util.Collection<java.lang.String>	getPermissionsScopeAssignedTo() Deprecated. Since 6.0.2, replaced bygetPermissions(Enum)
protected java.util.EnumSet<StateScope>	getScopes() Returns the scopes for a permission object.
WorkflowTransitionConfig	getTransition(java.lang.String transitionId) Returns the specified transition defined in this workflow state.
java.util.List<WorkflowTransitionConfig>	getTransitions() Returns all transitions defined for this state.
boolean	isArchived() Indicates if this state is an archival state.
boolean	isPublished() Indicates if this state is a published state.
boolean	isStart() Indicates if this state was defined as the workflow's start state.
protected java.util.Set<java.lang.String>	readPermissionsRoles(org.w3c.dom.Node[] permissionNodes) Returns an unmodifiable permission roles set.

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Field Detail

permissionsScope

protected java.util.Map<java.lang.String,java.util.Collection<java.lang.String>> permissionsScope

Constructor Detail

WorkflowStateConfig

public WorkflowStateConfig(org.w3c.dom.Node stateElement)
                    throws PortalException

Constructs a WorkflowStateConfig, parsing its data from a state XML Element.

Parameters:

stateElement - the state XML element that contains the state's data.

Throws:

PortalException

Method Detail

getColorLight

public java.lang.String getColorLight()

Returns the light color for displaying this state.

Returns:

a HTML valid color string, or null if this state has no light color defined.

getColorStrong

public java.lang.String getColorStrong()

Returns the strong color for displaying this state.

Returns:

a HTML valid color string, or null if this state has no strong color defined.

getDescription

public java.lang.String getDescription()

Returns the description for this state.

Returns:

this state's description, localizable using its workflow's string resource, or null if not defined.

See Also:

WorkflowConfig.getResource()

getId

public java.lang.String getId()

Returns the identifier for this state.

Returns:

the identifier for this state.

getImageLarge

public java.lang.String getImageLarge()

Returns the href for the large image icon to be used for this state.

Returns:

the href for the large image icon to be used for this state, or null if not defined.

getImageSmall

public java.lang.String getImageSmall()

Returns the href for the small image icon to be used for this state.

Returns:

the href for the small image icon to be used for this state, or null if not defined.

getName

public java.lang.String getName()

Returns the name for this state.

Returns:

this state's name, localizable using its workflow's string resource.

See Also:

WorkflowConfig.getResource()

isPublished

public boolean isPublished()

Indicates if this state is a published state.

Returns:

true if this state is a published state, false otherwise.

See Also:

lumis.content.workflow

isArchived

public boolean isArchived()

Indicates if this state is an archival state.

Returns:

true if this state is an archival state, false otherwise.

Since:

4.0.11

See Also:

lumis.content.workflow

isStart

public boolean isStart()

Indicates if this state was defined as the workflow's start state.

Returns:

true if this state was defined as the workflow's start state, false otherwise.

See Also:

lumis.content.workflow

getTransitions

public java.util.List<WorkflowTransitionConfig> getTransitions()

Returns all transitions defined for this state.

getTransition

public WorkflowTransitionConfig getTransition(java.lang.String transitionId)
                                       throws WorkflowException

Returns the specified transition defined in this workflow state.

Parameters:

transitionId - the transition's id.

Returns:

the transition.

Throws:

WorkflowException - if the transition was not found.

getPermissionsScopeAll

@Deprecated
public java.util.Collection<java.lang.String> getPermissionsScopeAll()

Deprecated. Since 6.0.2, replaced bygetPermissions(Enum)

Returns all permissions available for 'all' scope.

Returns:

the permissions for the given scope.

getPermissionsScopeAssignedTo

@Deprecated
public java.util.Collection<java.lang.String> getPermissionsScopeAssignedTo()

Deprecated. Since 6.0.2, replaced bygetPermissions(Enum)

Returns all permissions available for 'assignedTo' scope.

Returns:

the permissions for the given scope.

getScopes

protected java.util.EnumSet<StateScope> getScopes()

Returns the scopes for a permission object.

Returns:

the scopes.

Since:

6.0.2

getPermissions

public java.util.Collection<java.lang.String> getPermissions(StateScope stateScope)

Returns all permissions available for a given scope.

Parameters:

stateScope - the scope to have the permissions returned

Returns:

the permissions

Since:

6.0.2

readPermissionsRoles

protected java.util.Set<java.lang.String> readPermissionsRoles(org.w3c.dom.Node[] permissionNodes)
                                                        throws PortalException

Returns an unmodifiable permission roles set.

Parameters:

permissionNodes - the nodes containing the permissions definition.

Throws:

PortalException

getPermissions

protected java.util.Collection<java.lang.String> getPermissions(java.lang.Enum<?> scope)

Returns all permissions available for a given scope.

Parameters:

scope - the scope to have the permissions returned

Returns:

the permissions

Since:

6.0.2
